Portable Weighing Instrument BX101E4-20t

Product Introduction

Overview:

The BX101E4-20t portable weighing instrument represents a state-of-the-art solution for field-based weight measurement and axle load monitoring. This portable axle weighing system utilizes multiple welded and sealed load sensors configured in a unified, integrated ultra-thin structure that ensures exceptional portability and ease of deployment in diverse operational environments. Specifically engineered as a portable weighing instrument, the BX101E4-20t delivers reliable 20-ton capacity axle scale performance without compromising on mobility or accuracy.

The design philosophy behind this portable axle weighing system emphasizes practical robustness combined with field-ready convenience. Special protective treatment applied throughout the structure makes it exceptionally suitable for harsh environmental conditions and complex road scenarios where standard weighing equipment may fail. The plastic ramp is intelligently hinged directly to the scale body, forming a seamless single unit that eliminates setup complications and reduces operational downtime. By combining premium aviation aluminum with corrosion-resistant stainless steel materials, this axle scale 20 ton platform delivers exceptional structural integrity and extended service life, ensuring consistent performance across demanding industrial applications.

Key Design Features:

1. Multiple welded and sealed load sensors with unified, integrated ultra-thin structure for superior portability;

2. Specialized protective treatment engineered for harsh environments and complex road conditions;

3. Hinged plastic ramp integrated with scale body to form a compact single operating unit;

4. Premium aviation aluminum and stainless steel construction ensuring superior durability and corrosion resistance.

Applications and Industry Solutions:

The BX101E4-20t portable weighing instrument serves as a versatile solution across multiple industrial sectors and regulatory applications. This portable axle weighing system is extensively utilized for weighing and load control of loading vehicles throughout road transportation, construction, agriculture, forestry, and waste disposal operations. The 20-ton capacity of this axle scale makes it particularly valuable for verifying proper load distribution and preventing overweight violations that could compromise vehicle safety or damage infrastructure.

Administrative law enforcement agencies depend on portable weighing instruments like the BX101E4-20t for roadside compliance inspections and overload detection of commercial trucks. Beyond transportation monitoring, this portable axle weighing system provides essential testing capabilities for aircraft weight and center of gravity verification, critical operations within aerospace maintenance and certification protocols. Manufacturing facilities rely on this axle scale 20 ton capacity system for comprehensive testing of vehicle axle weight and axle weight distribution during automobile production line quality assurance procedures. Additionally, the portable weighing instrument proves invaluable for stability testing of specialized vehicles including forklifts, cranes, and other heavy-duty equipment where load distribution verification is essential for operational safety.

Detail Display

Technical Specifications and Performance Data:

The technical specifications demonstrate the precision engineering embedded within the BX101E4-20t portable weighing instrument. With a 20-ton rated load capacity, this portable axle weighing system provides exceptional accuracy through optimized sensitivity of 0.8±0.1 mV/V, ensuring reliable weight measurement across the entire operational range. The nonlinearity specification of ≤0.30%FS guarantees consistent measurement accuracy throughout the weight spectrum, while the repeatability tolerance of ≤0.05%FS confirms that consecutive measurements deliver virtually identical results, a critical requirement for regulatory compliance and load verification applications.

Temperature stability represents another critical performance dimension of this axle scale 20 ton system. Both sensitivity and zero-point temperature effects are maintained at 0.05%FS per 10°C, ensuring that the portable weighing instrument delivers consistent accuracy across wide temperature variations—a fundamental requirement for field deployment in diverse climatic conditions. The output impedance specification of 1000±10Ω provides reliable signal transmission to connected monitoring and recording equipment, while the insulation resistance of ≥1000MΩ at 100VDC safeguards against electrical interference and ensures data integrity. The eccentric load error tolerance of ≤1.5%FS confirms that the axle scale maintains measurement accuracy even when loads are not perfectly centered on the weighing surface. Additionally, the safe overload range of 120%FS provides protective headroom against accidental overloading while maintaining structural integrity.

The BX101E4-20t portable weighing instrument represents an investment in reliable, field-ready weighing technology designed to meet the demanding requirements of modern transportation, logistics, and industrial operations where accurate axle weight measurement and load verification are essential for safety, regulatory compliance, and operational efficiency.
